High-value AI Optical Sorter Designed For Pistachios. Uses Proprietary Deep Learning And RGB Cameras To Remove Visible Defects Such As Color, Shape,

Brand Name : PHOENIX

Model Number : H AI Optical Sorter

Place of Origin : Hefei

MOQ : 1

Price : Price Negotiable

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Delivery Time : 5-8 work days

Model : H1

Belt Width (mm) : 300

Voltage : 220V~50/60Hz

Power (kW) : 3.2

Dimension (mm) : 3385*1251*2127

Unpacked Weight (kg) : 710

Air Nozzle : 64

Contact Now

PHOENIX H Intelligent RGB Optical Sorter


PHOENIX H is an intelligent optical sorting machine specifically designed for the pistachio category. It utilizes an AI-driven, cost-effective RGB camera system paired with proprietary deep learning algorithms, focusing on high-precision identification of visible defects. It offers exceptional value, helping customers achieve the leap from preliminary sorting to quality upgrade. The algorithms support continuous iterative optimization based on new samples, ensuring sorting capabilities consistently evolve with changing needs.

Specifications
Model Belt Width (mm) Air Nozzle Air Pressure (MPa) Air Consumption (m³/min) Voltage Power (kW) Dimension (mm) Unpacked Weight (kg)
H1 300 64 0.6~0.8 <1.2 220V~50/60Hz 3.2 3385*1251*2127 710
H2 600 128 0.6~0.8 <2.4 220V~50/60Hz 3.6 3385*1826*2127 881
H4 1200 256 0.6~0.8 <3.6 220V~50/60Hz 4.4 3385*2426*2127 1121



High-value AI Optical Sorter Designed For Pistachios. Uses Proprietary Deep Learning And RGB Cameras To Remove Visible Defects Such As Color, Shape,


High-value AI Optical Sorter Designed For Pistachios. Uses Proprietary Deep Learning And RGB Cameras To Remove Visible Defects Such As Color, Shape,


Core Advantage: A High-Cost-Performance Solution Built for Pistachios

Efficient & Stable Mechanical Design

  • Compact Single-Layer Belt Design: Its compact structure enables rapid installation and plug-and-play operation, minimizing the time to start production.

  • Efficient Vibratory Feeding System: Ensures uniform material spread, effectively reducing product overlap and significantly enhancing sorting accuracy.

  • All Food-Grade Stainless Steel Body: Strictly complies with global food safety and hygiene standards, offering corrosion resistance and easy cleaning.

  • Sealed Sorting Chamber & Electrical Enclosure: Industrial-grade dustproof design guarantees stable operation even in dusty and harsh environments.

  • Quick-Release Belt Design: Allows for rapid belt removal without complex tools, simplifying maintenance and easily meeting stringent hygiene management requirements.

  • Field-Proven Dustproof System: Tested and verified in the market, ensuring long-term operational stability and consistent sorting performance.

  • Modular Size Options: Available in three belt widths—300mm, 600mm, and 1200mm—to flexibly accommodate varying capacity needs and support future production line upgrades.

Core Technology: AI-Powered 4-in-1 Intelligent Optical Sorting System
The proprietary deep learning algorithm is the core driver of the PHOENIX H. Through an efficient, cost-effective configuration, the system achieves multi-dimensional precision inspection, accurately identifying various visible defects in pistachios:

  • Color Defects: Dark spots, oxidation, yellow skin, uneven bleaching, abnormal color.

  • Shape Defects: Broken kernels, shriveled kernels, malformation, poor shell opening, empty shells, size non-conformity.

  • Processing Defects: Residual shell fragments, incomplete inner skin removal, attached skin.

  • Biological Contamination: Insect damage traces, visible mold spots, rot.

  • Foreign Material Contamination: Insects, stems and leaves, stones, glass fragments, other impurities.

Hardware Synergy for Precision Capture

  • High-Resolution RGB Color Imaging System: Precisely captures subtle defects, ensuring even small foreign objects and color variations are detected.

  • High-Intensity LED Lighting System: Provides a stable, uniform light field, guaranteeing image quality and laying a solid foundation for algorithmic analysis.

Precise Execution: High-Performance Pneumatic Ejector System

  • Optimized Design: Balances mechanical durability, high-speed response, and low air consumption for optimal efficiency and effectiveness.

  • Consistent Rejection: Maintains precise ejection action and consistent operational stability even under high-throughput sorting conditions.

  • Reduced Operating Costs: Significantly lowers the mis-ejection rate, effectively reducing product waste and optimizing overall operating costs.

Intelligent Interaction: 15-Inch Industrial Touchscreen Control System

  • Intuitive HMI: Features a high-definition industrial touchscreen with seamless multi-language support for easy operation.

  • One-Click Changeover: Pre-set sorting parameters allow for quick production mode changes when processing different batches or specifications, minimizing downtime for adjustments.

Comprehensive Support: All-Round Remote Assistance System

  • Remote Access & Real-Time Monitoring: Enables equipment status monitoring from anywhere, anytime.

  • Performance Data Dashboard: Visualizes key sorting metrics to assist in management decision-making.

  • Online Expert Diagnosis & Interactive Troubleshooting: Allows technical teams to intervene remotely, quickly identify issues, and provide solutions, maximizing production line continuity.
